Replacing the Photo Cartridge 53
R4CF95P
SHORT.bk
Rev. D
INK.FM A5 size
2/15/05
R Proof Sign-off:
H. Yamasaki CRE Nakano
M. Otsuka
editor name
En
glish
7. For best results, shake the new photo cartridge
four or five times before opening the package.
8. Remove the replacement photo cartridge from its
package.
c Caution:
❏ Do not touch the green IC chip on the
bottom of the cartridge. This can
damage the photo cartridge.
❏ If you remove the photo cartridge for
later use, be sure to protect the ink
supply ports from dirt and dust; store
it in the same environment as the
printer. Note that there is a valve in
the ink supply ports, making covers or
plugs unnecessary, but care is needed
to prevent the ink from staining items
that the cartridge touches. Do not
touch the ink supply ports or
surrounding area.
Do not touch this part.
