4 Mounting the Automatic Switch Box SMA Solar Technology AG
14 AS-BOX-M_L-IA-IEN110320 Installation Guide
4 Mounting the Automatic Switch Box
Requirements for the mounting location:
☐ Foundation consists of solid material.
☐ The foundation is suitable for the weight and dimensions of the Automatic Switch Box (see
section 10 ”Technical Data”, page 53).
☐ The mounting location is accessible at all times.
☐ Climatic conditions are met (see section 10 ”Technical Data”, page 53).
☐ Mounting location is not exposed to direct sunlight.
☐ Mounting location is protected against splashes of water.
☐ Technical connection requirements of the network operator are met.
Mounting position:
Figure 3: Permitted and prohibited mounting positions
Danger to life due to fire or explosion.
• Do not mount the Automatic Switch Box on flammable construction materials.
• Do not mount the Automatic Switch Box near highly flammable construction materials.
• Do not mount the Automatic Switch Box in potentially explosive areas.
