rt U Define the chamfer at contour point 3 : Enter the
chamfer width 10 mm and save with the END key
U Move to contour point 4 : Enter the Y coordinate 5 and
save your entry with the END key
U Define the chamfer at contour point 4 : Enter the
chamfer width 20 mm and save with the END key
U Move to contour point 1 : Enter the X coordinate 5 and
save your entry with the END key
U Depart the contour: Define the rounding radius of the
departing arc
U Retract the tool: Press the orange axis key Z in order
to get clear in the tool axis, and enter the value for the
position to be approached, e.g. 250. Confirm with the
ENT key
U Confirm Radius comp.: RL/RR/no comp? by pressing
the ENT key: Do not activate the radius compensation
U Confirm Miscellaneous function M? Enter M2 to end
the program and confirm with the END key: The TNC
saves the entered positioning block
Further information on this topic
„ Complete example with NC blocks: See “Example: Linear
movements and chamfers with Cartesian coordinates,” page 202
„ Creating a new program: See “Creating and Writing Programs,”
page 95
„ Approaching/departing contours: See “Contour Approach and
Departure,” page 189
„ Programming contours: See “Overview of path functions,” page
193
„ Tool radius compensation: See “Tool radius compensation,” page
178
„ Miscellaneous functions (M): See “Miscellaneous Functions for
Program Run Control, Spindle and Coolant,” page 300
