Programming: miscellaneous functions – HEIDENHAIN iTNC 530 (340 49x-05) ISO programming User Manual
Page 36
36
11.1 Overview of Special Functions ..... 322
Main menu for SPEC FCT special functions ..... 322
Program defaults menu ..... 323
Functions for contour and point machining menu ..... 323
Menu of various DIN/ISO functions ..... 324
11.2 Dynamic Collision Monitoring (Software Option) ..... 325
Collision monitoring in the manual operating modes ..... 327
Collision monitoring in Automatic operation ..... 329
Graphic depiction of the protected space (FCL4 function) ..... 330
Collision monitoring in the Test Run mode of operation ..... 331
11.3 Fixture Monitoring (Software Option) ..... 332
Setting parameters for the fixture: FixtureWizard ..... 334
Placing the fixture on the machine ..... 336
Check the position of the measured fixture ..... 338
11.4 Global Program Settings (Software Option) ..... 340
Technical prerequisites ..... 342
Activating/deactivating a function ..... 343
Superimposed mirroring ..... 347
Additional, additive datum shift ..... 347
Superimposed rotation ..... 348
Handwheel superimposition ..... 349
11.5 Adaptive Feed Control Software Option (AFC) ..... 351
Defining the AFC basic settings ..... 353
Recording a teach-in cut ..... 355
Activating/deactivating AFC ..... 358
Tool breakage/tool wear monitoring ..... 361
