GUIDE TO INSTALLATION AND OPERATION

SME-1901 / 1911 | 3

1.4 Front Card-edge Interface


The front card-edge of the SME-1901/1911
incorporates two elements:

• Status LED (see section 3.2)
• Select Button (see section 4)


The card extraction lever indicates the type of card that is installed
(SME-1901 shown).








Figure 1.3 Front card-edge layout

Select Button

IRD-3802

Status LED

S

ta

tu

s

S

e

le

c

t

SME-1901
