Configurations
Profile Video File Server Installation 1-13
Table 1-6. PDR404 Factory Standard Configurations with Installable Options
Slot PDR 404A PDR 404D PDR406A PDR406D
J1 System CPU System CPU System CPU System CPU
J2 Parallel Port Parallel Port Parallel Port Parallel Port
J3
J4 System SCSI System SCSI System SCSI System SCSI
J5 Audio I/O
Digital AES/EBU
Audio I/O
Digital AES/EBU
Audio I/O
Digital AES/EBU
Audio I/O
Digital AES/EBU
J6 Video Mixer
or
Video Out
Picture Monitor (Analog)
Video Mixer
or
Video Out
Picture Monitor (Analog)
Video Mixer
or
Video Out
Picture Monitor (Analog)
Video Mixer
or
Video Out
Picture Monitor (Analog)
J7 Audio I/O
Digital AES/EBU
or
Video Out
Picture Monitor (Analog)
Audio I/O
Digital AES/EBU
or
Video Out
Picture Monitor (Analog)
Audio I/O
Digital AES/EBU
or
Video Out
Picture Monitor (Analog)
Audio I/O
Digital AES/EBU
or
Video Out
Picture Monitor (Analog)
J8 Disk Recorder Slave Disk Recorder Slave Disk Recorder Slave Disk Recorder Slave
J9 Fibre Channel Fibre Channel Fibre Channel Fibre Channel
J10 Disk Recorder Master Disk Recorder Master Disk Recorder Master Disk Recorder Master
J11 DVCPRO Four-codec DVCPRO Four-codec DVCPRO Four-codec DVCPRO Four-codec
J12 DVCPRO Two-codec DVCPRO Two-codec DVCPRO Two-codec DVCPRO Two-codec
J13 Video I/O
Analog Composite
Video I/O
Serial Digital Component
Video I/O
Analog Composite
Video I/O
Serial Digital Component
J14 Video I/O
Analog Composite
Video I/O
Serial Digital Component
Video I/O
Analog Composite
Video I/O
Serial Digital Component
J15 Video I/O
Analog Composite
Video I/O
Serial Digital Component
Video I/O
Analog Composite
Video I/O
Serial Digital Component
J16 Reference / Timecode Reference / Timecode Reference / Timecode Reference / Timecode
J17 Remote I/O
RS422
Remote I/O
RS422
Remote I/O
RS422
Remote I/O
RS422
