Chapter 2 Using the Profile Configuration Manager
66 Profile Family
5. Under Monitor Channels, the Channel Selection box allows you to select
which channels you want to monitor. Click next to a channel pair to select
them. You can now adjust line levels for the pair.
6. The line level range is –12 to +0 dB. If you trim the line level for an
individual channel with the slider handle, the line level is incremented by 1
dB; clicking on either side of the slider handle increments the line level by
0.5 dB. The Level boxes show the current line level. If you enter a number
directly into a Level box, the line level number is rounded to the nearest
±
0.5
dB.
7. To adjust the trim for all channels at once, use the Group Fader slider.
While the Group Fader moves all channels at once, it maintains the
individual channel differences.
NOTE: If the audio interface box is not present, the Monitor group
will not appear. If your system is configured with an XLR 216 digital-
only chassis, channel selection is the only option available in the
Monitor Channels group.
8. Click OK to accept your changes or click another tab.
