22 Rev 1.0 • 01 Jul 10
4. Configuration
Panel Options
The following items are the checkbox options:
• User-programmable ID.
Allows the Panel ID to be changed locally at the control panel (in menu mode).
• Hold preset default.
Makes “hold” mode active when the panel reverts to its default state (after a ‘Default State’ but-
ton is pressed, or when the panel is restarted).
S Note: a ‘Hold’ button is needed only when you want the operator to be able to view or
change the mode.
• Enable destination lock.
Check ‘Enable Destination Lock’ so that any ‘Destination Lock’ button on the panel will func-
tion.
• Enable destination protect.
Check ‘Enable Destination Protect’ so that any ‘Destination Protect’ button on the panel will
function.
• Source master default.
Makes a machine-control-level source the controlling device (or master device) by default.
Otherwise, the destination is the master device by default. (The option is specifically for use
with NVISION series machine control routers.)
“Source is master” is used for duplication, or broadcast routing, on a machine control level.
“Destination is master” is for machine-to-machine editing. Regardless of the default, you can
place a ‘Source is Master’ button on the panel.
S Note: a ‘Source is Master’ button is a toggle that reverses the direction of data routing for
devices used in data level (machine control) takes.
• Hide sources not configured on this panel.
Causes the names of source devices that are not presently configured for this particular panel to
be effectively hidden. When another panel changes the source to one not configured for this
panel, this panel displays asterisks instead.
• Deselect all destinations and turn off hold after take.
After selecting many MD destinations (with ‘Hold’ mode on), it can be time-consuming to find
them all (and no others) to deselect them after a take. When you enable this option, the NV9616
does exactly that (and turns off hold mode).
You should not check this option unless you configure the panel with a ‘Hold’ button so the
operator can turn hold mode back on.
• Jump to multi-dest selection when switching to XY.
Makes the currently selected multi-destination device the preset destination when you switch
from MD mode to X-Y mode.
S The X-Y destination chosen is unpredictable when the panel is in MD “hold” mode and
multiple destinations are selected.
• Flip-flop source to preset after take.
Swaps the preset source and the currently routed source for this destination.
