Operation
Chapter 5 provides operating instructions for the NV9601 control panel.
Topics
Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Operating Concepts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Salvo Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Menu Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Setup Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
This chapter is intended specifically for the NV9601 panel operator.
Summary
As an NV9601 operator, you will be confronted initially with a relatively simple panel — 36
buttons and a scrollable alphanumeric display. The design of the user interface is entirely at the
discretion of the configurer. You, the user, depend on the configurer having designed a useful
panel.
The user interface of an NV9601 in one installation can be radically different from the user inter-
face of an NV9601 in another installation. It is impossible to describe operations in great detail
because there is no one interface. What we can do, however, is give you general advice and, of
course, specific information on the behavior of the different button types and operational
modes.
The panel’s buttons can have arbitrary legends (because they are inserts under the clear plastic
button caps). A button’s legend might or might not indicate its function. Operators and config-
urers will have to communicate about the meaning of the buttons.
The alphanumeric display (8 lines of 42 characters) shows the status of takes (pending or
complete) in X-Y mode or multi-destination mode under normal circumstances. The display
presents information or menu items as isolated cases warrant. You can scroll the display as
necessary.
Physically, you will find
• Function buttons (that, e.g., select a source or lock a destination).
• Selection buttons that select levels in X-Y mode and devices in MD mode.
• Status of preset and current sources and the selected destination(s).
At any particular time, some of the buttons are enabled or disabled. Some are high-tally; some
are low-tally; and some might be undefined.
 Please refer to the NV9000-SE Utilities User’s Guide (or the NV9000-SE Utilities help files) if you
are unfamiliar with the concepts used in this chapter.
