8977AP-4B/4U — Instruction Manual
Remote Configuration
Status Web Page
The Status web page (
for the 8977AP-4U with an
8900GEN-SM submodule installed and
for the
8977AP-4B with no submodule) shows the signal status of the input
signal(s) and communication with the frame bus. Color coding of the
display indicates the signal status. Refer to
for an explanation of the color coding. The con-
tents of the web page header is explained on
.
Module Physical Structure
Status is reported for each of the following audio and video signals:
•
Audio inputs – indicate the status of the four audio inputs (BNC or
3-pins connectors).
•
DT Input – indicates the status of the audio delay tracking input.
•
Ref 1 and Ref 2 In (from frame) – the Ref 1 arrow will be green when
Frame Bus 1 has been enabled on the module in slot 1. The Ref 2 arrow
will be green when Frame Bus 2 has been enabled on the module in
slot 3 of the frame.
•
Frame Bus – indicates the status of the communication bus to the
8900NET module.
•
Genlock Ref In – indicates the status of the external genlock reference
signal on the BNC.
•
Local Ref – indicates the status of the internally generated genlock ref-
erence signal from the 8900GEN submodule to the front module.
•
Ref Out – if the module is installed in slot 1, Ref 1 out is directed to the
Ref 1 In. If the module is installed in slot 3, Ref 2 out is directed to the
Ref 2 In.
On the Status web page any alarm or warning states will cause a warning
message to appear in the double bars area below the graphic.
Note
The color of the LED status is managed by the 8900NET accordingly to the
alarms status.
Status
The front, rear, and Genlock (if present) modules status is given: PASS,
WARNING, ERROR or EMPTY.
Front Module
There are information about the module, such as Part Number, Serial
Number, Hardware Revision, Package version, Firmware Version, Soft-
ware Version, Boot Version and Asset Tag number are given in a properties
section at the bottom of the Status web page.
