20 8977AP-4B/4U — Instruction Manual
Power Up
A red FAULT LED indicates an error situation and, when noted with the
other indicator LEDs, can indicate a specific problem area.
Table 1 describes
signal output and LED indications.
Table 1. LED Indicators
LED Indication Condition
FAULT
(red)
Off Normal operation
On continuously Module has detected internal fault.
Flashing Configuration problems or checking inputs and settings or missing audio
COMM
(yellow)
Off No activity on frame communication bus
On continuously Locate Module Command
Flashing Activity present on the frame communication bus
CONF
(yellow)
Off Module is in normal operation mode
On continuously Module is initializing, changing operating modes, or programming hardware
PWR
(green)
Off No power to module or modules DC/DC converter failed
On Normal operation, module is powered
FRM1
(green)
Off Reference frame bus is disabled to frame on Genlock web page or no Genlock submodule is installed in slot 1
On Reference frame bus is enabled on Genlock web page and Genlock submodule is installed in slot 1
FRM2
(green)
Off Reference frame bus is disabled to frame on Genlock web page or no Genlock submodule is installed in slot 3
On Reference frame bus is enabled on Genlock web page and Genlock submodule is installed in slot 3
TDM IN N/A Not used in this version
REF IN
(green)
Off The frame reference input coax is not present on the BNC Ref In or signal is not locked
On The frame reference input coax is present on the BNC Ref In and signal is locked
OPT PRES N/A Not used in this version
AES IN 1-4
(green)
Off No AES input signal detected
On One or more AES input signal detected
AES IN 5-8
(green)
N/A Not used in this version
