68
QSFP+
transceiver
module
Central
wavelength Connector
Cable
specifications
Mode bandwidth
(MHz*km)
Maximum
transmission
distance
QSFP-40G-L
R4-WDM13
00
4 lanes:
• 1271 nm
• 1291 nm
• 1311 nm
• 1331 nm
LC 9/125 μm SMF N/A
10 km (6.21
miles)
NOTE:
The QSFP-40G-SR4-MM850 and QSFP-40G-CSR4-MM850 transceiver modules can be used to connect
one 40G QSFP+ port to four 10G SFP+ ports. The QSFP+ transceiver modules and SFP+ transceiver
modules to be connected must be the same in specifications, including central wavelength and fiber type.
Table 24 QSFP+ DAC cable specifications
QSFP+ DAC cable Cable length Data rate Description
LSWM1QSTK0 1 m (3.28 ft) 40 Gbps Used for connecting 40 Gbps QSFP+ ports
LSWM1QSTK1 3 m (9.84 ft) 40 Gbps Used for connecting 40 Gbps QSFP+ ports
LSWM1QSTK2 5 m (16.40 ft) 40 Gbps Used for connecting 40 Gbps QSFP+ ports
Table 25 QSFP+ to SFP+ DAC cable specifications
QSFP+ to SFP+ DAC
cable
Cable length Data rate Description
LSWM1QSTK3 1 m (3.28 ft) 40 Gbps
Used for connecting a 40 Gbps QSFP+ port
to four 10 Gbps SFP+ ports
LSWM1QSTK4 3 m (9.84 ft) 40 Gbps
Used for connecting a 40 Gbps QSFP+ port
to four 10 Gbps SFP+ ports
LSWM1QSTK5 5 m (16.40 ft) 40 Gbps
Used for connecting a 40 Gbps QSFP+ port
to four 10 Gbps SFP+ ports
Table 26 CXP transceiver module specifications
CXP
transceiver
module
Central
wavelength
Connector
type
Cable
specifications
Modal
bandwidth
(MHz*km)
Max transmission
distance
CXP-100G-SR-M
M850
850 nm MPO
50/125 μm
OM3, MMF
2000 100 m (328.08 ft)
