Airaid Filter Co. 2688 E Rose Garden Ln. Phoenix AZ 85050 (800) 498-6951
REV.10.31.13
P/N 790-551 Aerosol Spray
P/N 790-550 Squeeze Spray
16. Double check your work!
Make sure there is no foreign material in the intake path. Make sure all clamps, hoses, bolts, and screws are tight.
17. Reconnect the negative battery cable!
11. Align the hole in the CAD with the hole in the
factory coolant reservoir mount. Insert one M6-1x25
hex bolt (#15) and 1/4” flat washer (#10) through the
hole in the CAD, through the coolant reservoir
mount, and into the speed nut below it.
12. Insert two ¼-20 x 7/8” bolts (#9) and ¼” flat
washers (#10) through the holes in the CAD and thru
the grommets. On the underside of the factory airbox
mounting plate, align the long/narrow bracket (#16),
two ¼” flat washers (#10), and two ¼-20 nuts (#12)
with the ¼-20 x 7/8” bolts. Tighten the assembly
securely.
13. Mount the Airaid Premium Filter (#1) onto the
filter adapter and tighten the clamp.
14. Install the weather strip (#5) onto the top edge of
the CAD as shown. (Hint: start at one end and work
your way around to the other.)
15. Slip the black plastic hose mount (#17) over the
radiator overflow hose. Next, place one ¼” flat wash-
er (#10) over the hole on the inner drivers side fend-
er. Slide the hose mount prongs thru the fender and
thru the washer.
10. Install the CAD assembly into the vehicle. First,
align the filter adapter with the factory MAF sensor
housing, then, secure it with the factory clamp.
Thank you for purchasing the Airaid Intake System. Contact Airaid @ (800) 498-6951 8:00 AM - 5:00 PM MST weekdays for questions
regarding fit or instructions that are not clear to you. Your Airaid Intake System was carefully inspected and packaged. Check that no parts are
missing, or were damaged during shipping. If any parts are missing, contact Airaid. The air filter element is protected from direct exposure to wa-
ter and debris; care should be taken not to drive through deep water. WATER INGESTION IS THE DRIVERS RESPONSIBILITY! The air filter
is reusable and should be cleaned periodically.
FILTER IDENTIFICATION
700-445 Airaid Oiled Media 701-445 Airaid SynthaMax Dry Media - Red
702-445 Airaid SynthaMax Dry Media - Black 703-445 Airaid SynthaMax Dry Media - Blue
For your Oiled media filter we
suggest using the AIRAID Filter
Tune-Up Kit!
Synthamax Air Filters do not require oil.
Service air filter as needed by cleaning
with common non-petroleum all-purpose
household cleaner and water. Simple
Green®, Formula 409® or equivalent
works great. Apply cleaner to outside of
air filter and allow to soak. Then flush
filter clean from the inside out with a gar-
den hose and repeat steps if necessary.
Do not apply high pressure water or air
to clean filter. Allow filter to air dry and
reinstall
.
