Airaid Filter Co. 2688 E Rose Garden Ln. Phoenix AZ 85050 (800) 498-6951
P/N 790-551 Aerosol Spray
P/N 790-550 Squeeze Spray
Thank you for purchasing the Airaid Intake System. Contact Airaid @ (800) 498-6951 8:00 AM - 5:00 PM MST week-
days for questions regarding fit or instructions that are not clear to you. Your Airaid Intake System was carefully inspected and
packaged. Check that no parts are missing, or were damaged during shipping. If any parts are missing, contact Airaid. The air
filter element is protected from direct exposure to water and debris; care should be taken not to drive through deep water. WA-
TER INGESTION IS THE DRIVERS RESPONSIBILITY! The air filter is reusable and should be cleaned periodically.
REV.11.6.13
FILTER IDENTIFICATION
700-452 Airaid Oiled Media 701-452 Airaid SynthaMax Dry Media - Red
702-452 Airaid SynthaMax Dry Media - Black 703-452 Airaid SynthaMax Dry Media - Blue
Synthamax Air Filters do not require
oil. Service air filter as needed by
cleaning
with
common
non-
petroleum all-purpose household
cleaner and water. Simple Green®,
Formula 409® or equivalent works
great. Apply cleaner to outside of air
filter and allow to soak. Then flush
filter clean from the inside out with a
garden hose and repeat steps if nec-
essary. Do not apply high pressure
water or air to clean filter. Allow fil-
ter to air dry and reinstall.
For your Oiled media filter
we suggest using the
AIRAID Filter Tune-Up Kit!
19. Double check your work, make
sure all nuts, bolts, and clamps are
securely fastened. Make sure there is
no foreign material in the intake
path. Re-connect the negative battery
cable.
13. Remove the factory hose from
step 2, and install the new 3/8”x 4”
hose on the end of the vacuum line as
shown. Reinstall vacuum line. (Refer
to step 2.)
14. Install the ¼” barbed fitting into
the intake tube.
15. Install hump hose on CAD with
#52 hose clamps, and the coupler on
the throttle body with #44 hose
clamps as shown.
16. Slide intake tube into the hump
hose first, and then into the coupler.
Adjust for a good fit, and tighten
hose clamps. Slide vacuum hose on
barbed fitting, and install speed
clamp as shown.
17. Replace the factory breather hose
with ½”x10” rubber hose between
valve cover and intake tube using
speed clamps as shown.
18. Install the Airaid Premium Filter
and the weather strip on the CAD, as
shown. (Hint: start the weather strip
near the radiator support and work
towards the back of the vehicle.)
