Installation Instructions
For Part Numbers:
300-190
700-445 Airaid Oiled Media Filter
301-190
701-445 SynthaMax Dry Media Filter - Red
302-190
702-445 SynthaMax Dry Media Filter - Black
303-190
703-445 SynthaMax Dry Media Filter - Blue
2006-08 Dodge Ram 1500/2500/3500
5.7L V8
2. Unlatch 4 clips on the factory airbox lid and
remove the lid and intake hose assembly. Re-
3. Squeeze the tab on the connector, and dis-
connect the intake temperature sensor.
4. Using a 10mm socket, remove two bolts
holding the intake resonator to the intake mani-
fold. Lift and pull the resonator away from the
5. Remove the factory seal from the throttle
body.
6. Gently twist the air temperature sensor
counterclockwise and remove it from the
7. Install the supplied grommet (#12) into the
Modular Intake Tube (#3). Next, carefully slide
the factory temperature sensor into the grom-
met until it touches the tab on the temperature
8. Install the Quick Fit Panel (#2) onto the factory
airbox base by sliding the tabs on the base thru
the Quick Fit Panel and then adjust the sides to
fit. Re-latch the 4 clips to hold the Quick Fit
9. Install the urethane hump hose (#4) onto
the tube on the Quick Fit Panel using two
Component Identification
1.
Airaid Premium Filter
1
2.
Quick Fit Panel
1
3.
Modular Intake Tube
1
4.
Urethane Hump Hose
1
5.
Reducing Coupler
1
6.
Weather Strip 32 3/4”
1
7.
Black Rubber Cap
1
8.
#52 Hose Clamp
2
9.
#60 Hose Clamp
2
10.
#14 Speed Clamp
1
11.
#24 Speed Clamp
1
12.
Rubber Grommet
1
10. Install the reducing coupler (#5), small
end first, onto the throttle body using two #52
hose clamps (#8). Leave the clamps loose for
now.
11. Install the Modular Intake Tube (#3) into
the hump hose first and then into the reducing
coupler. Adjust for fit, and then tighten all 4
hose clamps.
12. Install the provided rubber cap (#7)
and speed clamp (#10) onto the nipple on
the Modular Intake Tube, as shown.
1. Disconnect the negative battery cable!
Loosen the hose clamp on the resonator. Dis-
Full color instructions can be viewed on our web site at Airaid.com. Use the Product Search function to find your part number, and click View Details.
