Page 102
In this chapter
˽ Appendix A – Cable Connector Definitions
˽ Appendix B – Cable Lengths
˽ Appendix C – Click 221 User Reference Guide
˽ Appendix D – Preassembled Backplate
˽ Appendix E – Matrix Extended Range
˽ Appendix F – Command Line Arguments
11
Appendix A – Cable Connector Definitions
The connector end of the SmartSensor 6-conductor cable mates to the 8-pin connector on
the SmartSensor Matrix (see Figure A.1).
A
B
C
D
E
F
G
H
Figure A.1 – SmartSensor Matrix Connector
Appendix
