45
PRINTING
PRINTING FROM A PC
Reading: Cable# 1
Length Delay Skew Patch/Solid
25 ft. 38ns 2ns Patch
CERT LEVEL 1: 1 GIG, 100% TOL
CERT LEVEL 2: 1 GIG, 100% TOL
NEXT PASSED (DIGITAL TEST)
FEXT PASSED (DIGITAL TEST)
SPLIT PAIRS PASSED
WIREMAP:
PROPAGATION
DELAY (PER PAIR)
12> 25' === <12
36> 26' === <36
45> 26' === <45
78> 26' === <78
12> 0ns SKEW
36> 1ns SKEW
45> 1ns SKEW
78> 1ns SKEW
Cable Category (Digital test)
CAT3 CAT5 CAT5E CAT6
RW Certification #1
10MB/S 100MB/S 1000MB/S
RW Certification #2
10MB/S 100MB/S 1000MB/S
Data Signal Levels
PAIR 1,2 PAIR 3,6 PAIR 4,5 PAIR 7,8
Data Min
12> 38ns DELAY
36> 39ns DELAY
45> 39ns DELAY
78> 39ns DELAY
Typical RWC1000 printout
Note: If Level 2 testing was not performed, the Data Signal Levels and the RW
Certifi cation #2 charts will have no data.
