12
TASCAM HS-P82
Left side panel
f Cord holder
Use this to hold the cord of the included TASCAM PS-
1225L adaptor designed for this unit to prevent the plug
from becoming disconnected.
g DC IN connector
Connect the included TASCAM PS-1225L adaptor
designed for this unit here.
h COMPACT FLASH SLOT 2 (CF 2)
Insert a CF card here.
j COMPACT FLASH SLOT 1 (CF 1)
Insert a CF card here.
k EXT DC IN connector
Connect external DC power here. Use a supply with an
output voltage of DC 11-16 and an output current of 2A
or more. The connector is XLR-4-32 (1: –, 2: NC, 3:
NC, 4: +).
l DIGITAL I/O connector
Use this D-sub 25-pin AES3-2003/IEC60958-4 (AES/
EBU) format connector for digital audio input and
output. Transmission occurs at double speed when the
sampling frequency is 88.2/96 kHz and at quad speed
when 176.4/192 kHz. The digital input section includes
a sampling rate converter that is compatible with 32–216
kHz sampling frequencies.
; CASCADE/WORD/VIDEO (IN 2) connector
Use this BNC connector to input cascade, word clock
(44.1, 48, 88.2, 96, 176.4 or 192 kHz as well as 48 kHz
pull-up or pull-down) or video reference (NTSC/PAL
black burst, HDTV Tri-Level) signals.
z CASCADE/WORD (OUT 2) connector
Use to output word sync signals (44.1, 48, 88.2, 96,
176.4 or 192 kHz as well as 48 kHz pull-up or pull-
down).
x TIME CODE/DIGITAL (OUT 1) connector
Use this BNC connector to output SMPTE time code.
Internal settings can be changed to allow AES3-2003/
AES-3id-2001 (AES/EBU) format digital audio signal
to be output. Transmission occurs at double speed when
the sampling frequency is 88.2/96 kHz and at quad
speed when 176.4/192 kHz.
c TIME CODE (IN 1) connector
Use this BNC connector to input SMPTE time code.
v USB connector
Use a USB 2.0 cable to connect this unit to a computer.
Driver software is not necessary. The computer
recognizes each of the CF card slots in this unit as a
unique mass storage device, so two separate devices
appear on the computer if both slots contain cards. Use
the USB connection to transfer audio files on the CF
cards in this unit to the computer.
b KEYBOARD connector
Connect an IBM PC-compatible keyboard with a PS/2
interface, and use it to input project, scene, and channel
names, for example. By default, the unit is set to use a
US keyboard. When using a Japanese keyboard, since
the key allocation is different, change the setting on the
PREFERENCES
page of the
SYSTEM SETUP
screen.
2 − Names and functions of parts
