8-4 Print & Peel
Important Safety Features
Before using the Print & Peel System, become familiar with the following
important safety features.
1 2
1. Emergency Stop Button
The emergency stop button can be used to terminate power to both the
QLS-4100 Xe and the Print & Peel Base. Using this button shuts down
both systems immediately.
2. Rewind Switch
The rewind switch enables/disables the rewind motor in the Print & Peel
Base. If the motor is disabled and a print job is inadvertently sent to the
printer, the motor will not be turned on. Disable the motor when
threading the liner.
