Mapping cameras to terminals – OpenEye SaleGuard User Manual
Page 20
20
33112AB
After you have set up locations and recorders, you will need to assign cameras to the individual POS
terminals.
1.
Click
Application
, and then click
Camera to POS Terminal Mapping
.
2.
Select the corresponding
Location
.
3.
Select the recorder from the
DVRs
list.
4.
Select the
Terminal
number from the
Terminals
list.
5.
Drag the associated camera into the
Cameras on Terminal #
field.
6.
Click
Exit
when you have added all the appropriate cameras to the terminal.
Only terminals that have been used since SaleGuard was installed will appear in the
Terminals
list. You may need to log in and out of every register to populate the terminal list.
