24. Technical data
Max. guide numbers at ISO 100/21°, zoom 105 mm:
In the metric system: 58 In the imperial system: 192
12 auto apertures at ISO 100/21°:
f/1, f/1.4, f/2, f/2.8, f/4, f/5.6, f/8, f/11, f/16, f/22, f/32, f/45
Automatic aperture adjustment at ISO 100/21°:
f1.0 to f45, including intermediate values
Manual partial light output levels:
1/1 ... 1/256 light output, in one-third increments.
Flash durations see table 4, page 175:
Sensor measuring angle:
approx. 25°
Colour temperature:
approx. 5600 K
Film speed:
ISO 6 to ISO 6400
Synchronisation:
low-voltage ignition
Number of flashes (at full light output):
* Approx. 180 with NiMH batteries 1600 mAh
* Approx. 180 with high-capacity alkaline manganese batteries
* Approx. 430 with Metz Power Pack P76 (special accessory)
(at full light output)
Recycling time (at full light output):
* Approx. 5 sec with NiMH batteries
* Approx. 5 sec with high-capacity alkaline manganese batteries
* Approx. 2,5 sec with Power Pack P76
(at full light output)
Light coverage:
Main reflector from 24 mm (35 mm format)
Main reflector with wide-angle diffuser from 18 mm (35 mm format)
Secondary reflector from 35 mm (35 mm format)
Swivelling ranges and locking positions of the reflector
upwards -7° 45° 60° 75° 90°
counter-clockwise 30° 60° 90° 120° 150° 180°
clockwise 30° 60° 90° 120°
Dimensions, approx., in mm (W x H x D):
71 x 148 x 99
Weight:
355 gr
Included:
Flash unit with integrated wide-angle diffuser, operating instructions,
T58 bag, mounting foot
