1
1.1 Products Comparison Chart:
1 SYSTEM DESCRIPTION
The above listed systems provide secure and versatile power
reboot management access for communication equipment such
as routers, switches, and network devices. They are also the
ideal assistant devices for engineering development and test
applications. Key features include:
• Local Master Port access: offers data rates from 2400 to
115200 bits/second and optional hardware handshaking
(CTS/RTS). There are two operation modes for the port:
Console Transparent Mode and System Control Mode.
• Three user privilege login levels: The Administration level
manages system configuration and unconditional access to
all power outlets and all serial ports. The User level allows
each user to reserve and manage his/her own ports, as well as
to change most of system configuration settings. Anonymous
users are able to view all settings and operate unreserved
power outlets and serial console ports.
• User name and password for each port: Each port is user
name and password protected.
• Line commands or menu configuration controls: Menu
table operation offers user-friendly operation methods that are
used for changing system configurations, viewing run time
statuses, and issuing controls. Line commands provide quick
and easy operations.
• Telnet access: Remote access the system over a TCP/IP
network for configuration and control of the systems.
• Out of band Modem access interfacing: Control and
configure the system via a telephone line. Optional custom
Modem AT command string to the Modem.
• HTTP web access: Embedded web server provides secured
user name and password authentication. The operations are
easy and friendly, utilizing tables and graphical icons.
Download SNMP MIB files for convenience, or view an online
help manual.
• SNMP MIB capability: An SNMP (Simple Network
Management Protocol) agent is integrated in the system for
an exchange of management information between the system
and network devices.
• POP/SMTP Emailing with SMTP Authentication capability:
A user can send control commands such as reboot power
outlet via emails. Command execution reports are replied for
each command email received. SMTP user name and
password are protected through authentication process.
• SNMP Trap for sending logging message: The Trap is used
to asynchronously report events to the NMS. It forwards
power reboot command execution information to the remote
Trap logging receiver.
1.2 What you can do with the system:
• Remote equipment power source management over
TCP/IP networks, including rebooting user equipment, and
permanently turning on/off user power source. Schedule
power reboots or power source on/off events monthly, weekly,
daily or at any time an application requires. Reboot power
source to equipment when a network connection is lost.
• Monitoring AC Power Consumptions and sending warning
messages when the aggregated AC draw from a system is
crossed predefined threshold.
• Remote control anywhere by emailing. Via emails, you are
able to manage the systems or user communication
equipment power sources when LAN access is impossible. Via
emails, you can send user data to the NP control commands
such as rebooting user power source. Reply emails are sent
after the system intercepts incoming emails so that you are
informed with the operation status.
• AutoPing and reboot user equipment. Connect your
system to a power outlet and assign the system network
IP address or URL. The NP system will ping the user
equipment periodically (in every 15 seconds). If the user
Figure 1 - Product Comparison Chart
P O W E R C O M M A N D E R I Q
Model Chassis # of # of Input Total AC Input Power AC Current Network Regulatory
Outlets Power Current Cord Plug Monotoring Port ULSafety
Cords Output Type (Ethernet) & EMI
(Inlet) Amps
SPDU8 1-U 8 1 15 NEMA 5-15P Y Y UL60950-1/FCC
Class A
SPDU16 2-U 16 2 30 NEMA 5-15P Y Y UL/FCC Class A
SPDU20 0-U 20 1 20 NEMA L5-20P Y Y UL/FCC Class A
Vertical
