Page 77: Pin-outs for joystick and speedpot connector -29
InstallatIon
MicroEDGE Pro
Instruction Manual 807290
2-29
joystick and speedpot connector
• Cable connector: AMP 206037-1
• Pin contacts AMP 65105-3
• Cabling: Belden # 8308 or equivalent for encoder signals
• Hypertherm kit: 228837
Pin-outs for joystick and speedpot connector
Pin no.
Signal
1
Joystick up
2
Joystick down
3
Joystick left
4
Joystick right
5
Common
6
10 V reference
7
Speed pot 1+
8
Speed pot 1-
9
Common
10
10 V reference
11
Speed pot 2+
12
Speed pot 2-
13
Common
14
Common
15
Common
16
Common
