Picopath test plugs, Picopath test plugs -8 – Hypertherm MicroEDGE Pro Shape Cutting Control Rev.2 User Manual
Page 156
Parts List
5-8
MicroEDGE Pro
Instruction Manual 807290
Item
Part No.
Description
228833
tester kit: Picopath plugs
1
Tester for Picopath axes
2
Tester for Picopath I/O (white stripe)
Tester for Picopath I/O (orange stripe)
3
Tester for THC (Picopath)
4
Tester for Picopath joystick and speedpot (brown stripe)
Picopath test plugs
The following testers are used for diagnostic testing on Picopath models of the MicroEDGE Pro CNC.
1
2
3
4
