2 Hydraulic 3/3.25 7/17/08
A B C D E
34 1 /
2
"
876 mm
24 1 /
8
"
613 mm
20 5 /
8
"
524 mm
9 1 /
2
"
241 mm
10 3 /
4
"
273 mm
F G H I J
12"
305 mm
7 1 /
4
"
184 mm
7 3 /
8
"
200 mm
7 3 /
4
"
197 mm
12"
305 mm
DIMENSIONS *Unit with 7 /
8
" (22.2 mm) clevis
*Subtract 3 /
8
" (10 mm) for 3 /
4
" (19 mm) clevis. Add 1 /
2
" (13 mm) for
1" clevis (A to F only).
Table of Contents Dimensions
Warranty — Online at www.harken.com or call, write,
email or fax Harken, Inc., Pewaukee, WI USA
■ TABLE OF CONTENTS
General Specifications
Dimensions .......................................................................2
Stainless Surface, Port Side Up, Hoses and Fittings .......3
Drain System, Valves, Pressure, Oil .................................4
Parts ............................................................................... 5 - 6
Preparation
Headstay Cut Length, Connectors ....................................7
Foil Cut Length, Top Foil Cut Length ................................8
Short Top Foil, Connector and Foil Quantity ....................9
Cutting Top Foil .................................................................9
Assembly
Foil Assembly ...............................................................10 - 11
Attach Stay – Rod Unit 3 .................................................12
Stay to Lower Unit Connection - Rod Unit 3.25 .............13
Attach Stay – Wire ...........................................................14
Lower Toggle and Cowling ..............................................15
Install Torque Tube, Raise Foils .......................................16
Foil Length Check ...........................................................17
Raise Unit; Gear Box Pressure ........................................18
Install Hoses, Oil Level, Headstay Tension......................19
Halyard Wraps .................................................................20
Pendants ..........................................................................21
Halyard Restrainer ...........................................................21
Halyard Tension ...............................................................22
Backstay Tension .............................................................22
Before Operation, Manual Operation ...............................23
