MDE-4643 Quarles NBS Configuration and Software Installation Manual · March 2007
Page 7
Site Configuration
Page 4
• 35. Use remote verification (reader) - Credit
• 50. Keypads - If Gilbarco
®
CRIND
®
, Tokheim
®
DPT or Wayne
®
CATS are used, this
parameter will be filled in. If Gasboy Island Card Readers (ICRs) are used, this line can be
left blank. Refer to MDE-4316 Site Controller III Configuration Manual for the
appropriate entries when using third party (Gilbarco, Wayne or Tokheim) readers.
• All other items on Page 4 can retain their default value.
Page 5
• Quarles sites are currently card reader-access only. The default settings on Page 5 can be
used.
Page 6
• If a gate reader is used, refer to MDE-4316 Site Controller III Configuration Manual for
information on setting up this page.
Page 7
• If Fuel Point is used, refer to MDE-4316 Site Controller III Configuration Manual for
information on setting up this page.
Page 8
• 85. Remote port channel - 6 (can be 4, 5 or 6). Refer to
to identify appropriate port numbers.
• 86. Log printer channel - 1
• 88. Remote port baud rate - 2400
• 94. Host handler channel - 4
• 95. Host handler baud rate -2400
• 96. Verification timeout (routers) - 95
• 100. Send requests to host handler - Credit
• All other items on Page 8 can retain their default settings.
Page 9
• 107. Blank pump display after - Never
• All other items on Page 9 can retain their default settings.
Page 10+11
• All items on Page 10+11 can retain their default settings.
CAUTION
The Host Handler Channel (94), Host Handler BAUD rate (95), and Host Handler Data (101)
should not be changed here. Changes in network parameters pertaining to modem type and
other configuration settings that are important to credit verification will automatically change
this parameter. Making changes here may render the credit verification system inoperable.
This operation should only be performed at the suggestion of the Gasboy Technical
Assistance Center.
