Introduction
Page 2 MDE-4528A Gasboy® External Filter Kit Installation Instructions · November 2007
Parts List
The following table lists the parts included in this kit. Refer to Figure 1 on page 5 for the
illustration showing the parts included in the kit.
Item Description Part Number Quantity
1 Elbow, 1-1/2 x 45 024877 1
2 Pipe TBE 1-1/2 x 4 -3/4 044943 1
3 Bushing, Hex 2 x 1-1/2 017288 1
4 Elbow, Street 1-1/4 x 90 017171 1
5 Bushing Face 2 x 1-1/4 017287 1
6 Filter Adapter 1-1/2” NPT Single Element CIM-TEK 810 025902 1
Filter Adapter 2” NPT Double Element CIM-TEK 820 025903 1
7 Nozzle Hook 003719 1
8 Filter Element CIM-TEK 800-10 (Standard) or 025900 2
Filter Element CIM-TEK HS10 (Hydro) 025901 2
9 Filter Gasket (Cold Weather Fluorosilcone) CIM-TEK 90546 M06450B001 2
10 Assy, Filter Cap and Gasket, High Capacity R18896-G1 1
11 Strainer Insert, High Capacity R19457 1
Warranty
For information on warranty, refer to MDE-4255 Gasboy’s Warranty Policy Statement. If you
have any warranty-related questions, contact Gasboy’s Warranty Department at its Greensboro
location.
