03/07/03 4-1
Section 4
START-UP
COMPLETION CHECK LIST
The information below should be reviewed to help verify the proper installation of the satellite
dispensing unit. If the installation does not meet criteria listed, correct the problem before
the start-up is performed.
1.
If connected to a Series 9800A dispenser, to avoid damage to the CPU PCB board,
verify that the RESET COMPLETE, FAST FLOW, SUBM. STARTER DRIVE, and SLOW
and FAST SATELLITE RETURN wires are not shorted to conduit or chassis.
2.
The unit must be properly secured to the island.
3.
All plumbing must be complete and tight. All liquid-carrying lines must be checked for
leaks.
4. All conduit work must be complete. All junction box covers must be secured. Conduits
should not be sealed until the wiring is verified through proper operation.
5.
The unit must be properly grounded.
6. Before any testing begins, remove any water in the tank through a fill opening, using a
suitable pump. Do not use the GASBOY pump or dispenser and submersible pump to
remove water. Serious damage may occur.
7.
A sufficient volume of fuel must be put in the tank to insure that the liquid level is high enough
to allow the submersible pump to operate efficiently (dispensers).
START-UP
After successfully verifying the installation against the completion check list, the unit is ready for
start-up. Follow the procedure listed below to perform an orderly start-up of the satellite
dispensing unit.
1.
Turn on the circuit breaker(s) for the various control lines to the dispenser to be tested.
2.
Remove the nozzle for Side 1 from its holder and turn on the pump handle.
3. Dispense fuel. If the unit contains a slow/fast flow valve, verify that it opens. Check all
plumbing for leaks at this time.
4.
Turn the pump handle off. Open the nozzle. No fuel should be dispensed.
5.
For twin models, repeat Step 1 to Step 4 for the other untested dispenser.
