Create RAID5 (Parity)

1. Select “

1.Create RAID Volume” from the main menu and press .

2. In "

Name" item, you can input a device name for the RAID5 system and press

to apply it. Here, we name it as TryRAID5 to replace the default Volume0.

3. In “

RAID Level” item, you can use Up or Down arrow key to make a selection from

one of RAID0, 1, 5, 10 items. Select RAID5(Parity) and press .

Intel(R) Matrix Storage Manager option ROM v5.0.0.1011 ICH9R wRAID5

Enter a unique volume name that has no special characters and is

16 characters or less.

[↑↓]-Change [TAB]-Next [ESC]-Previous Menu [ENTER]-Select

Intel(R) Matrix Storage Manager option ROM v8.5.0.1013 ICH10R wRAID5

[

HELP

]

Name:

RAID Level:

Disks:

Strip Size:

Capacity:

Volume0

RAID0(Stripe)

Select Disks

128KB

0.0 GB

Create Volume

TryRAID5

[

CREATE VOLUME MENU

]

Intel(R) Matrix Storage Manager option ROM v5.0.0.1011 ICH9R wRAID5

Choose the RAID level:

RAID 0: Stripes data (performance).

RAID1: Mirrors data (redundancy).

RAID 10: Mirrors data and stripes the mirror.

RAID 5: Stripes data and parity.
