6. It will skip “
Strip Size” menu for RAID1.
7. In “
Capacity” item, use the default value, and press
hard disk 232.9GB is becoming the default value, and it indicates the maximum
capacity.
8. Select “
Create Volume” and press
Press
WARNING: ALL DATA ON SELECTED DISKS WILL BE LOST.
Are you sure you want to create this volume ? (Y/N) :
Intel(R) Matrix Storage Manager option ROM v5.0.0.1011 ICH9R wRAID5
Copyright(C) 2003-04 Intel Corporation All Rights Reserved.
1. Create RAID Volume
3. Reset Disks to Non-RAID
2. Delete RAID Volume
4. Exit
RAID Volume :
* = Data is Encrypted
ID
Name
Level Stripe Size
Status Bootable
0
TryRAID1
RAID1(Mirror) N/A 232.9GB
Normal
Yes
Physical Disks:
Port Drive Model
Serial #
Size
Type/Status(Vol ID)
0
WDC WD2500JS-60N WD-WCANKC865380 232.9GB
Non-RAID Disk
2
Maxtor 6L250S0
L50SKP4G
232.9GB
Member Disk(0)
4
ST3320620SV
9QF4YJGQ
298.1GB
Member Disk(0)
5
ST3300831AS
3NF02XH2
279.5GB
Non-RAID Disk
[↑↓]-Select [ESC]-Exit [ENTER]-Select Menu
Intel(R) Matrix Storage Manager option ROM v8.5.0.1013 ICH10R wRAID5
Copyright(C) 2003-08 Intel Corporation. All Rights Reserved.
[
DISK/VOLUME INFORMATION
]
[
MAIN MENU
]
1. Create RAID Volume
Intel(R) Matrix Storage Manager option ROM v5.0.0.1011 ICH9R wRAID5
Copyright(C) 2003-04 Intel Corporation All Rights Reserved.
The default value indicates the maximum capacity using the selected
disks. Entering a lower capacity allows you to create a second
volume on these disks
Intel(R) Matrix Storage Manager option ROM v8.5.0.1013 ICH10R wRAID5
Copyright(C) 2003-08 Intel Corporation. All Rights Reserved.
Name:
RAID Level:
Disks:
Strip Size:
Capacity:
TryRAID0
RAID0(Stripe)
Select Disks
N/A
465.8 GB
Create Volume
[↑↓]-Change [TAB]-Next [ESC]-Previous Menu [ENTER]-Select
[
HELP
]
232.9
[
CREATE VOLUME MENU
]
