Voltage Options
► CPU Over Voltage
This item is used to set CPU Over Voltage.
► Multiplier for CPU Voltage
This item is used to set CPU Voltage Multiplier.
► 1.8V VRAM Voltage Control
This item is used to change the voltage of memory group(1.8V).
The default option is: [Default].
► 1.28X Memory Voltage table
Enable this function, the practical memory voltage wil be 1.28 times of the memory group
voltage.
► 1.13X Memory Voltage table
Enable this function, the practical memory voltage wil be 1.13 times of the memory group
voltage.
► 1.5V STR Voltage Control
This item is used to set STR Voltage.
The default voltage is 1.50V.
► 1.1V MCH Voltage Control
This item is used to set MCH Voltage.
The default voltage is 1.10V.
► 1.2V FSB VTT Voltage Control
This item is used to set CPU VTT Voltage.
The default voltage is 1.2V.
► CPU PLL Voltage Setting
This item is used to set DRAM Voltage. The default voltage is 1.5V.
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Voltage Options
Voltage Options
Help Item
Min. Value(0)=1.20V
CPU Over Voltage
[8]
Max. Value(64)=1.60V
Multiplier for CPU Voltage
[0]
Stepping = 6.25mV
Voltage = value*multi
1.8V VRAM Voltage Control
[Default]
1.28X Memory Voltage table
[Disabled]
1.13X Memory Voltage table
[Disabled]
1.5V STR Voltage Control
[3]
1.1V MCH Voltage Control
[3]
1.2V FSB VTT Voltage Control
[0]
CPU PLL Voltage Setting
[3]
↑↓←→:Move Enter:Select +/-/:Value F10:Save ESC:Exit F1:General Help
F9:Optimized Defaults
[8]
