Foxconn ELA User Manual
Page 13
1
6
9. Audio Ports
For the definition of each audio port, please refer to the table below :
* : Please refer to Chapter 4, and install the Realtek audio driver (in CD) to assign the audio
output ports for different applications of 2/4/5.1/7.1 channels. The fundamental audio outputs
are depicted in the table above.
Port
2-channel
4-channel
5.1-channel
7.1-channel
Blue
Line In
Line In
Line In
Line In
Green
Line Out
Front Speaker Out
Front Speaker Out
Front Speaker Out
Pink
Microphone In
Microphone In
Microphone In
Microphone In
Orange
-
-
Center/Subwoofer Out Center/Subwoofer Out
Black
-
Rear Speaker Out
Rear Speaker Out
Rear Speaker Out
Grey
-
-
-
Side Speaker Out
