3

32

Power Management Setup

ACPI (Advanced Configuration and Power Interface) is an open industry standard interfaces
enabling OS-directed configuration, power management, and thermal management of mobile,
desktop, and server platforms. It defines five sleeping states, they are :

S1 - The S1 sleeping state is a low wake latency sleeping state. In this state, no system

context is lost (CPU or chip set) and hardware maintains all system context. (also called
Power on Suspend)

S2 - The S2 sleeping state is a low wake latency sleeping state. This state is similar to the S1

sleeping state except that the CPU and system cache context is lost (the OS is respon-
sible for maintaining the caches and CPU context). Control starts from the processor’s
reset vector after the wake event.

S3 - The S3 sleeping state is a low wake latency sleeping state where all system context is lost

except system memory. CPU, cache, and chip set context are lost in this state. Hardware
maintains memory context and restores some CPU and L2 configuration context. Control
starts from the processor’s reset vector after the wake event. (also called

Suspend to

RAM)

S4 - The S4 sleeping state is the lowest power, longest wake latency sleeping state supported

by ACPI. In order to reduce power to a minimum, it is assumed that the hardware platform
has powered off all devices. Platform context is maintained. (also called

Suspend to

Disk)

S5 - The S5 state is similar to the S4 state except that the OS does not save any context. The

system is in the “soft” off state and requires a complete boot when it wakes. Software
uses a different state value to distinguish between the S5 state and the S4 state to allow
for initial boot operations within the BIOS to distinguish whether or not the boot is going to
wake from a saved memory image.

► Suspend Mode

This item is used to set the energy saving mode of the ACPI function. When you select “S1
(POS)” mode, the power is always on and computer can be resumed at any time. When
you select “S3 (STR)” mode, the power will be down after a period of time. The status of the

CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.

Power Management Setup

Suspend Mode

S3(STR)

Help Item

Power On after Power Fail

[Power Off]

Wake On PME

[Enabled]

Select the ACPI

Wake On USB Devices

[Enabled]

state used for

Wake On PS2 Mouse

[Enabled]

System Suspend.

Resume On RTC Alarm

[Disabled]

↑↓→←:Move Enter:Select +/-/:Value F10:Save ESC:Exit F1:General Help

F9:Optimized Defaults

[S1 (POS)]
