Gladiator bIoS
► CPU Configuraion/Voltage Options
Press
► DRAM Timing Selectable
This item is used to enable/disable provision of DRAM timing by SPD device. The Serial
Presence Detect (SPD) device is a small EEPROM chip, mounted on a memory module. It
contains important information about the module's speed, size, addressing mode and various
other parameters, so that the motherboard memory controller (chipset) can better access the
memory. When this item is set to [Disabled], following items will appear.
CAS Latency Time
This item controls the CAS Latency.The CAS Latency is the number of clock cycles that
elapse from the time the request for data is sent to the actual memory location until the data is
transmitted from the module.
Precharge Delay
This item allows you to set the precharge delay time (in clock cycles).
RAS# Precharge
This item allows you to select the DRAM RAS precharge time (in clock cycles).
RAS# to CAS# Delay
This item allows you to select a delay time (in clock cycles) between the CAS# and RAS#
strobe signals.
Write to Precharge
This item allows you to set Write to Precharge delay (in clock cycles).
Row Refresh Cycle
This item allows you to set Row Refresh Cycle (in clock cycles).
Write to Read Delay
This item allows you to set minimum Write-to-read delay (in clock cycles).
Row to Row Delay
This item allows you to set Row to Row Delay (in clock cycles).
Read to Precharge
This item is used to set the read CAS to precharge time (in clock cycles).
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
