► Keyboard
The system boot will not stop for a keyboard error if you enabled this item.
► Mouse
The system boot will not stop for a mouse error if you enabled this item.
► Floppy
The system boot will not stop for a floppy error if you enabled this item.
► Model Name
Model name of this product.
► BIOS Version
It displays the current BIOS version. User can check this information and discuss with the field
service people if a BIOS upgrade is needed.
► Memory
This item displays the current memory size. The size is depending on how many memory mod-
ules were installed in your system before powering on.
► MAC Address
This item shows the onboard LAN MAC address.
► CPU Name
It displays the current CPU name.
Mapping Table :
With PATA IDE drives Without PATA IDE drives
With PATA IDE
drives
OnChip ATA Devices OnChip ATA Devices
OnChip ATA
Devices
SATA#1 Configuration
Compatible/Enhanced SATA#1 Configuration
Disabled
SATA#1 Configuration
Compatible/Enhanced SATA#1 Configuration
Disabled
Configure
SATA#1 as
SATA#2 Configuration SATA#2 Configuration SATA#2 Configuration SATA#2 Configuration RAID AHCI
Enhanced Disabled Enhanced Disabled Enhanced Disabled Enhanced Disabled 6 ports 6 ports
Primary IDE Master SATA 1 SATA 1 SATA 5 ESATA SATA 1 SATA 1 SATA 5 ESATA ESATA ESATA
Primary IDE Slave SATA 3 SATA 3 - - SATA 3 SATA 3 - - - -
Secondary IDE Master SATA 2 SATA 2 SATA 6 IDE0 SATA 2 SATA 2 SATA 6 - IDE0 IDE0
Secondary IDE Slave SATA 4 SATA 4 - IDE1 SATA 4 SATA 4 - - IDE1 IDE1
Third IDE Master SATA 5 ESATA ESATA - SATA 5 ESATA ESATA - - -
Third IDE Slave - - - - - - - - - -
Forth IDE Master SATA 6 IDE0 IDE0 - SATA 6 - - - - -
Forth IDE Slave - IDE1 IDE1 - - - - - - -
Fifth IDE Master ESATA - - - ESATA - - - - -
Fifth IDE Slave Not Used
Sixth IDE Master IDE0 - - - - - - - - -
Sixth IDE Slave IDE1 - - - - - - - - -
