Page 36

level interface for a Host Controller for Serial ATA. The specification includes a description of
the hardware/software interface between system software and the host controller hardware.
AHCI provides more advanced features including SATA features, but some SATA drives may
not support AHCI, unless they are labeled with AHCI support in its specification.
If your motherboard supporting AHCI, and you have a SATA device, which also supports AHCI,
then you can select IDE option to have fair performance (only PATA, SATA level), or you can
select AHCI to get its best performance.

► SATA#2 Configuration

SATA#2 are the SATA ports 5,6 of the motherboard. This item allows you select the mode of
the SATA ports. Setting values are: [Disabled], [Enhanced].

► JMicron 36x ATA Controller

This item is used to select the operating mode for JMicron 36x ATA controller.Setting values
are: [Disabled], [IDE Mode] and [AHCI + IDE Mode].

OnBoard Devices

► OnBoard LAN

This item is used to enable or disable the onboard LAN controller.

► OnBoard LAN Boot ROM

This item is used to enable or disable the onboard LAN boot optional ROM. A LAN boot ROM
lets you set up a diskless workstation on the network. By installing a boot ROM in the network
board, you can enable a client PC system on the network to be booted remotely.

► OnBoard 1394

This item is used to enable or disable the onboard 1394 devices.

► USB Functions

This item is used to enable or disable USB function.

► HDA Controller

This item is used to enable or disable the HD Audio Controller.

► Auto Detect PCI Clock

This option is used to auto detect PCI slots. When enabled, the system will turn off clock of the
empty PCI slot to reduce EMI (Electromagnetic Interference).

OnBoard Devices

OnBoard LAN

[Enabled]

Help Item

OnBoard LAN Boot ROM

[Disabled]

OnBoard 1394

[Enabled]

USB Functions

[Enabled]

HDA Controller

[Enabled]

Disabled

Auto Detect PCI Clock

[Disabled]

Enabled

↑↓←→:Move Enter:Select +/-/:Value F10:Save ESC:Exit F1:General Help

F9:Optimized Defaults

[Enabled]

Options
