SuperIO Configuration

► OnBoard Floppy Controller

This item is used to enable/disable onboard Floppy Controller.

► Floppy Drive Swap

This BIOS feature is used to logically swap the mapping of drives A: and B:. Therefore, it is
only useful if you have two floppy drives.
Normally, the sequence by which you connect the floppy drives to the cable determines which
is drive A: and which is drive B:. If you attach the floppy drives the wrong way and obtain a
drive mapping that is not to your satisfaction, the usual way of correcting this is to physically
swap the floppy cable connectors.
This feature allows you to swap the logical arrangement of the floppy drives without the need
to open up the case and physically swap the connectors.
When this BIOS feature is enabled, the floppy drive that originally was mapped to drive A: will
be remapped to drive B: and vice versa for the drive that was originally set as drive B:.
When this BIOS feature is disabled, the floppy drive mapping will remain as that set by the
drive connector arrangement.
Although this appears to be nothing more than a feature of convenience, it can be quite impor-
tant if you are using two floppy drives of different form factors (3.5" and 5.25") and you need
to boot from the second drive. Because the BIOS can only boot from drive A:, you will have to
physically swap the drive connections or use BIOS this feature to do it logically.

► IR Function

This item is used to enable/disable onboard infrared chip function.

► IR Duplex Mode

This item enables you to determine the transfer mode of the onboard infrared chip.Setting
values are: [Full Duplex], [Half Duplex].

► Power LED

This item is used to enable/disable OnBoard Power LED: Power On Button, Reset Button
and Clear CMOS Button.

SuperIO Configuration

Configure ITE8720 Super IO Chipset

Help Item

OnBoard Floppy Controller

[Enabled]

Allows BIOS to Enable

Floppy Drive Swap

[Disabled]

or Disable Floppy

IR Function

[Enabled]

Controller.

IR Duplex Mode

[Half Duplex]

Power LED

[Enabled]

↑↓←→:Move Enter:Select +/-/:Value F10:Save ESC:Exit F1:General Help

F9:Optimized Defaults

[Enabled]
