Creating raid 1 – Foxconn ELA User Manual
Page 85
5
78
4. It then goes to “
Disks” item. Press
system.
5. From the hard drive list, use Up or Down arrow key to reach the hard disks you want
to combine them as RAID0, then press
will appear to indicate the drive selected. Here, we select two 232.9GB hard disks as
an example. Press
Creating RAID 1
Intel(R) Matrix Storage Manager option ROM v5.0.0.1011 ICH9R wRAID5
Copyright(C) 2003-04 Intel Corporation All Rights Reserved.
Intel(R) Matrix Storage Manager option ROM v8.5.0.1013 ICH10R wRAID5
Copyright(C) 2003-08 Intel Corporation. All Rights Reserved.
Name:
RAID Level:
TryRAID0
RAID0(Stripe)
[↑↓]-Change [TAB]-Next [ESC]-Previous Menu [ENTER]-Select
Port Drive Model
Serial #
Size
Status
0 WDC WD2500JS-60N WD-WCANKC865380 232.9GB Non-RAID Disk
2 Maxtor 6L250S0
L50SKP4G
232.9GB Non-RAID Disk
4 ST3320620SV
9QF4YJGQ
298.1GB Non-RAID Disk
5 ST3300831AS
3NF02XH2
279.5GB Non-RAID Disk
Select 2 to 6 disks to use in creating the volume
[↑↓]-Prev/Next [SPACE]-SelectDisk [ENTER]-Done
[
SELECT DISKS
]
0 WDC WD2500JS-60N WD-WCANKC865380 232.9GB Non-RAID Disk
[
CREATE VOLUME MENU
]
Creating RAID 1
Name:
RAID Level:
Volume0
RAID0(Stripe)
Intel(R) Matrix Storage Manager option ROM v5.0.0.1011 ICH9R wRAID5
Copyright(C) 2003-04 Intel Corporation All Rights Reserved.
Port Drive Model
Serial #
Size
Status
►
0 WDC WD2500JS-60N WD-WCANKC865380 232.9GB Non-RAID Disk
►
2 Maxtor 6L250S0
L50SKP4G
232.9GB Non-RAID Disk
4 ST3320620SV
9QF4YJGQ
298.1GB Non-RAID Disk
5 ST3300831AS
3NF02XH2
279.5GB Non-RAID Disk
Select 2 to 6 disks to use in creating the volume
[↑↓]-Prev/Next [SPACE]-SelectDisk [ENTER]-Done
2 Maxtor 6L250S0
L50SKP4G
232.9GB Non-RAID Disk
Intel(R) Matrix Storage Manager option ROM v8.5.0.1013 ICH10R wRAID5
Copyright(C) 2003-08 Intel Corporation. All Rights Reserved.
[↑↓]-Change [TAB]-Next [ESC]-Previous Menu [ENTER]-Select
[
CREATE VOLUME MENU
]
[
SELECT DISKS
]
