Appendix B DeviceNet Object| CME-DN01
Revision October 2007, 2006PDD23000003 B-9
Class 0x95 DataConf Object
Class attributes
Attribute ID Access Rule Name Data Type
1 Get Revision UINT
Instance 1
Attribute
ID
Access
Rule
Name Data Type Description
2 Get/Set Config_flag USINT
0: CME-DN01 will use this object for
I/O message
1: CME-DN01 use default setting.
3 Get/Set NetCtrl USINT
0: controlled local.
1: controlled by network.
4 Get/Set NetRef USINT
0: set speed local,
1: set speed by network.
5 Get/Set LossDNTreat USINT
0: Ignore and continue
1: Stop according to “Stop method”.
17 Get/Set dlen_in USINT Length of input data
18 Get/Set Dlen_out USINT Length of output data
19 Get/Set Data_in[0] UINT 1
st
word input data
20 Get/Set Data_in[1] UINT 2
nd
word input data
21 Get/Set Data_In[2] UINT 3
rd
word input data
22 Get/Set Data_in[3] UINT 4
th
word input data
23 Get/Set Data_in[4] UINT 5
th
word input data
24 Get/Set Data_in[5] UINT 6
th
word input data
25 Get/Set Data_in[6] UINT 7
th
word input data
26 Get/Set Data_in[7] UINT 8
th
word input data
