Delta Electronics DeviceNet CME-DN01 User Manual
Page 21
Chapter 5 Troubleshooting| CME-DN01
Revision October 2007, 2006PDD23000003
5-3
State
Indication
Corrective Actions
Red LED
Connection failure/no
connection
1.
To check if the connection between the AC
drive and RS-485 of CME-DN01 is correct.
2.
Re-wire the AC drive connection and ensure
that the wire specification is correct.
