Appendix B DeviceNet Object| CME-DN01
Revision October 2007, 2006PDD23000003 B-3
Class 0x02 Message Router
The Message Router Object provides a messaging connection point to serve any object class or
instance in the Client.
Class attributes
Attribute ID Access Rule Name Data Type
1 Get Revision UINT
6 Get MaxIdClass UINT
7 Get MaxIdInstance UINT
Instance 1
Attribute ID Access Rule Name Data Type
2 Get NumAvailable UINT
3 Get NumActive UINT
Common Services
Implemented for
Service Code
Class Instance
Service Name
0x0E Yes Yes Get_Attribute_Single
