Chapter 4 Configuration| CME-DN01
4-2 Revision October 2007, 2006PDD23000003
Attribute
ID
Access
Rule
Name Data Type Description
49 Get/Set Data_out[0] UINT 1
st
word output data
50 Get/Set Data_out[1] UINT 2
nd
word output data
51 Get/Set Data_out[2] UINT 3
rd
word output data
52 Get/Set Data_out[3] UINT 4
th
word output data
53 Get/Set Data_out[4] UINT 5
th
word output data
54 Get/Set Data_out[5] UINT 6
th
word output data
55 Get/Set Data_out[6] UINT 7
th
word output data
56 Get/Set Data_out[7] UINT 8
th
word output data
Common services
Implemented for
Service Code
Class Class
Service Name
0X05 Yes Yes Reset
0x0E Yes Yes Get_Attribute_Single
0x10 No Yes Set_Attribute_Single
Explanation: User can set following variables for DataConf object by the requirement.
1. dlen_in/dlen_out: for user to select input/output length when communicating with
DeviceNet network. Maximum length of dlen_in/dlen_out is 16 bytes.
NOTE
After changing these two settings, the settings of Rx size and Tx size of I/O Parameters in
scanner module is needed to be same as these two settings. Or there will be fault and cannot
connect to DeviceNet network when running CME-DN01.
