PREMIER LEAF and LAWN VACUUM

Parts List - Blower Assembly - 8.5 TQ, B

&

S Engine

NOTE: Part numbers listed are available through DR Power Equipment.

Ref# Part#

Description

01

229311 Engine & Blower Assembly, E/S

244991 Engine & Blower Assembly, E/S, CA

229361 Engine & Blower Assembly, M/S

245021 Engine & Blower Assembly, M/S, CA

02

245131 Caster, Plate and Wheel, 2"

03

189821 Cap, End, 1/4"

04

189811 Nipple, 1/4" x 1-1/2" L

05

164141 Rivet, Pop, Alum., 3/16" Dia. x 3/16"

06 186931 Engine

Mount

07

114701 Bolt, 1/4"-20 x 1/2" HCS, LG

08

110731 Nut, Nylon Lock, 1/4"-20

09

223831 Engine, 8.5 TQ, B&S, E/S

245071 Engine, 8.5 TQ, B&S, E/S, CA

223851 Engine, 8.5 TQ, B&S, M/S

245051

Engine, 8.5 TQ, B&S, M/S, CA

10

134431 Bolt, 5/16"-18 x 1-1/2", HCS, LG

11

110761 Nut, Nylon Lock, 5/16"-18

12

164521 Key, Square, 1/4" x 2"

13

112431 Washer, Lock, Split, 5/16"

14

180811 Washer, Lock, Split, 3/8"

15

112411 Washer, Flat, 5/16", USS

16

186901 Housing, Inlet, Front

17 225731 Bracket,

Switch

18

188721 Harness, Safety, w/Switches

19

110781 Nut, 5/16"-24, Low Profile

20

123211 Bolt, 5/16"-18 x 3/4", HCS, LG

21 188331 Adapter,

Hose

22

112381 Washer, Flat, 1/4" USS

23

221141 Nut, Wing, 5/16"-18

24

192511 Wire Harness (E/S)

25

192501 Bracket, Key Switch (E/S)

26

145291 Bolt, Carriage, 5/16"-18 x 3/4" (E/S)

27

113081 Key Switch w/B805 Hardware (E/S)

28 192441 Battery

Bracket

Ref# Part#

Description

29

104831 Battery, 12V, 17AH (E/S)

30

124511 Battery Clamp, 7-1/8"W x 5-1/2"H

(E/S)

31

111481 Bolt, 1/4"-20 x 1-3/4", HCS, LG (E/S)

32

112481 Washer, Lock, 1/4", External Tooth

(E/S)

33

150141 Cable, Ground, 16" (E/S)

34

193031 Spacer, .328" ID x .750" OD x .625"

LG

(E/S)

180281 Spacer, .328" ID x .750" OD x .250"

LG

(M/S)

35

193351 Bolt, 5/16"-24 x 1-1/2" (E/S)

178821 Bolt, 5/16"-24 x 1" (M/S)

36

188811 Housing, Engine Side

37

188691 Impeller w/o Knife

38

193021 Spacer, Impeller (E/S)

39

165131 Bolt, 3/8"-24 x 1-1/4", HCS

40

233701 Knob, Engine Mount, 5/16"-18 x 1"
