English- 17
Pr. Explanation Settings
Factory
Setting
NOTE
8-01 DC Braking Time during Start-Up d0.0 to d60.0 Sec d0.0
8-02 DC Braking time during Stopping d0.0 to d60.0 Sec d0.0
8-03 Start-Point for DC Braking d0.0 to d400 Hz d0.0
8-04
Momentary Power Loss Operation
Selection
d0: Operation stops after
Momentary Power Loss
d1: Operation continues after
momentary power loss, speed
search starts with the Master
Frequency reference value
d2: Operation continues after
momentary power loss, speed
search starts with the minimum
frequency
d0
8-05
Maximum Allowable Power Loss
Time
d0.3 to d5.0 Sec d2.0
8-06 B.B. Time for Speed Search d0.3 to d5.0 Sec d0.5
8-07 Current Limit for Speed Search d30 to d200% d150
8-08 Skip Frequency 1 Upper Limit d0.0 to d400 Hz d0.0
8-09 Skip Frequency 1 Lower Limit d0.0 to d400 Hz d0.0
8-10 Skip Frequency 2 Upper Limit d0.0 to d400 Hz d0.0
8-11 Skip Frequency 2 Lower Limit d0.0 to d400 Hz d0.0
8-12 Skip Frequency 3 Upper Limit d0.0 to d400 Hz d0.0
8-13 Skip Frequency 3 Lower Limit d0.0 to d400 Hz d0.0
8-14 Auto Restart After Fault d0 to d10 d0
d0: Enable
d1: Disable
8-15 AVR Function
d2: Disable when deceleration
d2
115V/230V series: d350 to d450V d380
8-16
Software Braking Level
460V series: d700 to d900V d760
8-17 DC Braking Lower Bound Limit d0.0 to d400 Hz d0.0
Group 9 Communication Parameters
Pr. Explanation Settings
Factory
Setting
NOTE
a 9-00
Communication
Address
d1 to d254 d1
d0: Baud Rate 4800 bps
a 9-01 Transmission Speed
d1: Baud Rate 9600 bps
d1
a 9-01 Transmission Speed
d2: Baud Rate 19200 bps
d3: Baud Rate 38400 bps
d1
d0: Warn and Keep Operating
d1: Warn and Ramp to Stop
d2: Warn and Coast to Stop
a 9-02
Transmission Fault
Treatment
d3: Keep Operating without Warning
d0
d0: Disable
a 9-03 Time-out Detection d1 to d20: time setting (1 sec
increment)
d0
d0: 7,N,2 (Modbus, ASCII)
d1: 7,E,1 (Modbus, ASCII)
d2: 7,O,1 (Modbus, ASCII) a 9-04 Communication
Protocol
d3: 8,N,2 (Modbus, ASCII)
d0
