English- 13
Pr. Explanation Settings
Factory
Setting
NOTE
3-06
Multi-Function Output Terminal 2
(Relay Output)
d1: AC Drive Operational
d2: Master Frequency Attained
d3: Zero Speed
d4: Over Torque Detection
d5: Base-Block (B.B.) Indication
d6: Low-Voltage Indication
d7: Operation Mode Indication
d8: Fault Indication
d9: Desired Frequency Attained
d10: PLC Program Running
d11: PLC Program Step Completed
d12: PLC Program Completed
d13: PLC Program Operation
Paused
d14: Terminal Count Value Attained
d15: Preliminary Count Value
Attained
d16: AC Motor Drive Ready
d17: FWD command Indication
d18: REV command Indication
d8
Group 4 Input Function Parameters
Pr. Explanation Settings
Factory
Setting
NOTE
a 4-00 Potentiometer Bias Frequency d 0.0 to d 100.0% d0.0
a 4-01
Potentiometer Bias
Polarity d0: Positive Bias
d1: Negative Bias
d0
a 4-02
Potentiometer
Frequency Gain
d1 to d200 % d100
4-03
Potentiometer Reverse
Motion Enable d0: Forward Motion Only
d1: Reverse Motion enabled
d0
4-04
Multi-Function Input Terminal 1 (M0,
M1)
d0: No Function
d1: FWD/STOP, REV/STOP
d2: FWD/REV, RUN/STOP
d3: 3-wire Operation Control Mode
d4: E.F. External Fault Input (N.O.)
d1
4-05
Multi-Function Input Terminal 2 (M2) d5: E.F. External Fault Input (N.C.)
d6: Reset
d7: Multi-Step Speed Command 1
d8: Multi-Step Speed Command 2
d9: Multi-Step Speed Command 3
d10: Jog Operation
d11: Accel/decel Inhibit
d6
4-06
Multi-Function Input Terminal 3 (M3) d12: First or Second
Acceleration/deceleration Time
Selection
d13: External base block (N.O.)
d14: External base block (N.C.)
d7
4-07
Multi-Function Input Terminal 4 (M4) d15: Up: Increment master
frequency
d16: Down: Decrement master
frequency
d17: Run PLC Program
d8
