English- 16
Pr. Explanation Settings
Factory
Setting
NOTE
6-09 Second Most Recent Fault Record
6-10 Third Most Recent Fault Record
d8: Reserved
d9: Excess current during
acceleration (ocA)
d10: Excess current during
deceleration (ocd)
d11: Excess current during steady
state (ocn)
d12: Ground fault (GF)
d13: Reserved
d14: Low voltage (Lv)
d15: CPU failure 1 (cF1)
d16: CPU failure 2 (cF2)
d17: Base block (b.b.)
d18: Overload (oL2)
d19: Auto acceleration/deceleration
failure (cFA)
d20: Software protection enable
(codE)
d21: Reserved
d22: CPU failure (cF3.1)
d23: CPU failure (cF3.2)
d24: CPU failure (cF3.3)
d25: CPU failure (cF3.4)
d26: CPU failure (cF3.5)
d27: CPU failure (cF3.6)
d28: CPU failure (cF3.7)
d29: Hardware protection failure
(HPF.1)
d30: Hardware protection failure
(HPF.2)
d31: Hardware protection failure
(HPF.3)
d32: Communication time-out
(CE10)
d33: Reserved
d34: Software error (SErr)
d35: Reserved
d36: PID error (Pld)
d37: Reserved
d38: Phase loss (PHL)
d0
Group 7 Motor Parameters
Pr. Explanation Settings
Factory
Setting
NOTE
a 7-00 Motor Rated Current d30 to d120% d85
a 7-01 Motor No-Load Current d0 to d90% d50
a 7-02 Torque Compensation d0 to d10 d1
a 7-03 Slip Compensation d0.0 to d10.0 d0.0
Group 8 Special Parameters
Pr. Explanation Settings
Factory
Setting
NOTE
8-00 DC Braking Voltage Level d0 to d30% d0
