CSAT-5060/XSAT-7080 Transceiver iPAQ Link Revision 2
Introduction MN/CiLink.IOM
1–2
1.2 Using Memory Expansion Cards
The HP iPAQ Pocket PC supports Secure Digital / Multimedia Memory Cards (SD/MMC) such
as the HP 512MB MINISD shown in Figure 1-1. While not required for normal operation (and
not provided by CEFD), these expansion cards offer the advantage of being able to transfer a
software program such as CiLink between handheld devices, as permissible under the End User
License Agreement.
Figure 1-1. SD/MMC
(not included with kit)
1.3 HP iPAQ rx1950 Series Pocket PC – Key Operational Specifications Reference
Operating system Microsoft Windows Mobile 5.0 for Pocket PC
Processor Samsung 300Mhz
Memory 32MB SDRAM / 64MB ROM
Display
3.5-inch transflective Thin Film Technology (TFT) display color display,
16-bit (64 colors), 240 x 320 maximum resolution
Expansion (1) SD/MMC slot (SDIO)
Connectivity Integrated WiFi (IEEE 802.11b), Serial infrared (IrDA port), USB
Power
1100mAh removable / rechargeable lithium-ion battery;
100-240V~400mA 50-60Hz LPS AC power adapter
Operating humidity range 0-90%
Miscellaneous compliance
standards
UL, CUL, NOM, CAS NRTL/C, FCC Class B Certified
IMPORTANT
The HP iPAQ’s CPU features a flash-
memory controller that ensures
preconfigured and stored CiLink
®
settings are retained even if the
iPAQ’s rechargeable 1100mAh
lithium-ion battery gets low or fails
completely.
