CLC-10 Comtech LPOD Controller Handheld Terminal M&C Accessory Revision 3
Serial-Based M&C using the CLC-10 MN-CLC10
3–32
Parameter Type
Command
(Instruction
Code and
Qualifier)
Arguments
for Command
or Response
to Query
Description of Arguments
(Note that all arguments are printable ASCII characters)
Response to
Command
(Target to
Controller)
Query
(Instruction
Code and
Qualifier)
Response to Query
(Target to
Controller)
Remote Baud
Rate
SBR= 4 bytes Command or Query.
Sets or returns the remote baud rate in the form xxxx, where:
2400=2400 baud
4800=4800 baud
9600=9600 baud (default value)
19K2=19200 baud
38K4=38400 baud
Note: When changing baud rates remotely the response to the command will be returned using the same baud
rate as that used to send the command.
Examples: <1/SBR=9600’cr’
>0001/SBR=9600’cr’’lf’
<1/SBR?’cr’
>0001/SBR=09600’cr’’lf’
SBR=
SBR?
SBR*
SBR? SBR=xxxx
(See Description of
Arguments)
Switch Bias Tee SBT= 1 byte
numeric
Command or Query.
Sets or returns switching of the bias tee into the through state or into the off state, in the form x, where:
0=Off State (mute LNB) (default value)
1=Through State (unmute LNB)
Notes:
1. The bias tee provides a means of muting the LNB. The SBT state will be controlled by the amplifier mute state
while running in redundant mode, but while the unit is not in redundant mode the bias tee may be set
independently of the amplifier mute state.
2. To send this command the unit must have the bias tee option installed otherwise a mode error will result. A
mode error will also result if this command is sent while the unit is running in redundant mode.
Example: <1/SBT=1
SBT=
SBT?
SBT*
SBT? SBT=x
(See Description of
Arguments)
Set FSK Address SFA= 2 bytes,
numeric
Command or Query.
Sets or returns the FSK Address in the form xx, where:
xx=01-15
Default value: 01
Example: <1/SFA=01’cr’
>0001/SFA=’cr’’lf’
SFA =
SFA?
SFA*
SFA? SFA=xx
(See Description of
Arguments)
Summary Fault
Status E
N/A 1 byte Query only.
Returns the condition of the summary fault relay in the form x, where:
0=Not Faulted (SumFLT_COM J6 pin K is not connected to SumFLT_NC J6 pin M)
1=Faulted (SumFLT_COM J6 pin K is connected to SumFLT_NC J6 pin M)
Example: <1/SFS?
>0001/SFS=0’cr’’lf’
SFS= SFS? SFS=x
(See Description of
Arguments)
