CLC-10 Comtech LPOD Controller Handheld Terminal M&C Accessory Revision 3
Serial-Based M&C using the CLC-10 MN-CLC10
3–31
Parameter Type
Command
(Instruction
Code and
Qualifier)
Arguments
for Command
or Response
to Query
Description of Arguments
(Note that all arguments are printable ASCII characters)
Response to
Command
(Target to
Controller)
Query
(Instruction
Code and
Qualifier)
Response to Query
(Target to
Controller)
Retrieve Next 5
Unread Stored
Statistics
N/A 75 bytes Query only.
Returns the oldest 5 unread stored statistics entries in the reply format: {CR}Sub-body{CR}Sub-body{CR}Sub-
body{CR}Sub-body{CR}Sub-body, where:
Sub-body= ddmmyyhhmmssaaa.abbb.bccc.cdd.ddefghhh.hiii.i
ddmmyy=day/month/year
hhmmss=hour:minute:second
aaa.a=Operating Temperature (I.E. +40.0)
bbb.b=Amp Temperature (I.E. +40.0)
ccc.c=RF Power output
dd.dd=Attenuation Setting
e=Amp On/Off
f =Mute On/Off
g=Online/Offline Status
hhh.h=LNB Current (mA)
iii.i=BUC Tuning Voltage
If there are less than 5 entries to be retrieved, the remaining positions are padded with zeros. If there are no new
entries, the response is RNS*.
RNS= RNS? RNS={CR}Sub-
body{CR}Sub-
body{CR}Sub-
body{CR}Sub-
body{CR}Sub-body
(See Description of
Arguments)
Serial Number E N/A 9 bytes Query only.
Returns the unit’s 9 digit serial number in the form of xxxxxxxxx.
Example: <1/RSN?’cr’
>0001/RSN=072282040’cr’’lf’
RSN= RSN? RSN=xxxxxxxxx
(See Description of
Arguments)
Retrieve Utility
Status
N/A 23 bytes,
alpha- numeric
Query only.
Returns the utility status of the unit.
Example: <1/RUS=’cr’
>0001/RUS=’cr’
ADR=0001’cr’
BDR=09600’cr’
REF=087’cr’’lf’ (see Note)
Note: REF will only appear if a reference oscillator is installed.
RUS= RUS? RUS=x….x
(See Description of
Arguments)
