CLC-10 Comtech LPOD Controller Handheld Terminal M&C Accessory Revision 3
Serial-Based M&C using the CLC-10 MN-CLC10
3–28
Parameter Type
Command
(Instruction
Code and
Qualifier)
Arguments
for Command
or Response
to Query
Description of Arguments
(Note that all arguments are printable ASCII characters)
Response to
Command
(Target to
Controller)
Query
(Instruction
Code and
Qualifier)
Response to Query
(Target to
Controller)
Reference
Oscillator Tuning
REF= 3 bytes Command or Query.
Sets or returns the reference oscillator tuning voltage adjustment by sending a DAC value in the form xxx,
where:
xxx=is a numeric value from 0 to 255.
Default value: 087
Note: This command sets the DAC value, but the actual Reference Oscillator tuning voltage can be monitored
using the RMS command.
Example: <1/REF=087’cr’
>0001/REF=’cr’’lf’
REF=
REF?
REF*
REF? REF=xxx
(See Description of
Arguments)
Retrieve
Equipment Type E
N/A 22 bytes Query only.
Returns a string indicating the Model Number and the version of the M&C firmware installed in the unit.
Example: <1/RET?’cr’
>0001/RET=PS2053-5967-C REF BUC VER: 1.5.2’cr’’lf’
RET= RET? RET=x….x
(See Description of
Arguments)
RF Power FET
Current Status
N/A variable length
depending on
the number of
FETs installed
in the RF
amplifier
Query only.
Returns all FET currents in the form xx.x when the value is >1 Amp, or xxx when the value is < 1 AMP
Example: <1/RFS? ’cr’
>0001/RFS=’cr’
Q01=.xxx’cr’
Q02=.xxx’cr’
Q03=xx.x’cr’
Q04=xx.x’cr’
Q05=xx.x’cr’
Q06=xx.x’cr’
Q07=xx.x’cr’
Q08=xx.x’cr’
Q09=xx.x’cr’
Q10=xx.x’cr’
Q11=xx.x’cr’
Q12=xx.x’cr’
Q13=xx.x’cr’
Q14=xx.x’cr’
Q15=xx.x’cr’
Q16=xx.x’cr’’lf’
RFS= RFS? RFS=x….x
(See Description of
Arguments)
